Morgana - Digifold Pro (2014)

Creasing Machine

Current State: In stock

Last update: 10-09-2024 | Viewed: 647 times - Enquiry's: 20

PD Ref: 123458

Age: 2014
Max.Size: 70 x 38 cm (27 x 14 inch)

Latest Enquiry for this machine was from Bangladesh.

Technical Description:

Automatic crimping and folding machine

Technical parameters:

Maximum format - 700 x 385 mm
Minimum format - 210 x 140 mm
Max. grammage - 400 g/m2
Min. grammage - 80-100 g/m2
Min. sheet thickness - 0.11 mm
Max. the number of bigs on the sheet - 9
Max. number of quarries - 2
Maximum number of programs - unlimited
Min. distance between bigs - 40 mm
Min. distance of the big from the front edge - 50 mm
Min. length of stock from the front edge - 50 mm
Minimum rebate length - 70 mm
Minimum distance between breaks - 70 mm
Max. speed - depends on the characteristics of the paper - up to 6000 A4/hour
Dimensions - 1980 x 655 x 1265 mm
Weight - 190 kg
