PD Ref: 138398
Dealer Ref.# FGT 27-113
Age: 2004Max.Size: 33 x 0 cm (12 x 0 inch)
Main Technical Specifications • Web width: max. 330 mm • Max. web speed: 200 m/min • Max. inspection speed: 150 m/min (100% inspection) • Unwind roll diameter: max. 700 mm • Rewind roll diameter: max. 500 mm • Core diameter: 76 mm (pneumatic expanding shafts) • Web tension control: 0.5 – 10 kg, continuously adjustable • Electronic web guiding system (Fife with ultrasonic sensor) Slitting & Finishing • Shear knife slitting unit • 3 upper and lower knives included • Fine adjustment in 0.05 mm increments • Integrated edge trim extraction • Pneumatic splice unit • Integrated label and meter counter Inspection System fleyeVision print machine (100% inspection) • Matrix camera (1380 x 1040 pixels) • Flash illumination • Detection of print defects such as missing print, register deviation, stains, missing labels, missing text, matrix waste Inkjet System Imaje S8 Master 2.2G • Two nozzles per printhead • Suitable for marking up to 4 label lanes • Fully integrated into central machine control
Located: Europe Western
Available: Immediately
Phone: + 0049 711 490914-10 View Dealers Machines list
Send Email
Save
Or Call: + 0049 711 490914-10 FGT Graphic Machinery, Germany
