GM DC Nano 330 (2019)

Label-Finishing Machine

Current State: In production

Last update: 29-05-2026 | Viewed: 138 times - Enquiry's: 2

PD Ref: 141793

Dealer Ref.# 303664

Age: 2019
Max.Size: 33 x 0 cm (12 x 0 inch)

Latest Enquiry for this machine was from United Kingdom.

Technical Description:

Web Width: 200 - 330 mm

Substrate Thickness: 20 - 200 microns

Unwinder maximum reel diameter: 500 mm

BST Web Guide - Servo-driven web-tension control

Precision Cutting to reduce waste

Lamination Unit maximum diameter: 300 mm

Semi and Full-Rotary Die Cutting Unit

Repeat Length: 2 - 22”

Speed semi-rotary: 32 m/minute

Speed full-rotary: 50 m/minute

Die plate size: 50,8 - 558,8 mm

Splice Table

Rewinder maximum reel diameter: 400 mm

Slitting Unit with pneumatic crush knives

Matrix Waste Rewind

10” Color Touch Display

Power and Air: 3x 400V N PE / 16 A / 5 bar air
