Horizon RD 4055 (2015)

---

Age: 2015
Max.Size: 55 x 40 cm (21 x 15 inch)

---

Technical Description:

The Horizon RD-4055 / RD-N4055 Rotary Die-Cut System is a compact and highly productive rotary die-cutting solution designed to improve the quality and efficiency of short-run die-cutting production.

The machine is suitable for a wide range of applications, including business cards, greeting cards, labels, stickers, light packaging, pocket folders, tags, door hangers, and other digitally or offset printed products. It can perform die-cutting, kiss-cutting, creasing, waste separation, and stacking in one efficient workflow.

Thanks to its air suction feed belt, servo-controlled sheet transport, intuitive touch-screen operation, and optional delivery modules, the RD-4055 offers fast setup, accurate registration, stable production, and easy operation without the need for a highly skilled operator.

The system also includes a Repeat-Cut function, which allows multiple-up applications to be produced using a smaller die, helping to reduce die costs and improve production flexibility.

Sheet size before processing:
Max. 400 × 550 mm
Min. 200 × 275 mm

Processed material:
Normal paper, coated paper, cardboard

Material weight range:
127.9 to 400 gsm

Material thickness:
RD-N4055:
Die-cutting: max. 0.5 mm with 0.8 mm blade height
Die-cutting: max. 0.3 mm with 0.6 mm blade height
Creasing: max. 0.4 mm with 0.8 mm blade height

RD-N4055DM:
Die-cutting: max. 0.5 mm
Creasing: max. 0.3 mm

Production speed:
Up to 6,000 cycles/hour
With ST-4055 stacker: up to 3,000 sheets/hour

Feeder pile height:
Max. 500 mm

Feeder load capacity:
Max. 100 kg

Upper die size:
Max. 400 × 560 mm
Min. 160 × 100 mm

Upper cutting blade height:
RD-N4055: 0.6 or 0.8 mm
RD-N4055DM: 0.8 mm

Cut product size with SPC-N4055 separator:
Max. 376 × 530 mm
Min. 80 × 50 mm / 50 × 80 mm

Cut product size with CSD-40RD card stacker:
Max. 297 × 210 mm, A4 landscape
Min. 80 × 50 mm / 50 × 80 mm

Cut product size without SPC, with BT or ST delivery:
Max. 384 × 530 mm
Received sheet size: max. 400 × 550 mm

Power supply:
Single phase 200–240 V, 50/60 Hz
Single phase 230–240 V, 50/60 Hz for CE version

Recommended air source:
Oil-free compressor
Required pressure: 0.55 to 0.95 MPa
Required discharge: 85 litres/minute
Rated output reference: 0.75 kW

Machine dimensions depending on configuration:
With SPC-N4055 separator: 3,471 × 820 × 1,195 mm
With SPC-N4055 CSD-40RD: 4,253 × 820 × 1,195 mm
With SPC-N4055 GST-50RD: 3,770 × 2,300 × 1,195 mm
With ST-4055 stacker: 3,309 × 830 × 1,195 mm

Machine weight depending on configuration:
With SPC-N4055 separator: approx. 1,095 kg
With SPC-N4055 CSD-40RD: approx. 1,165 kg
With SPC-N4055 GST-50RD: approx. 1,332 kg
With ST-4055 stacker: approx. 1,026 kg

---

Located: Europe Central

---

---

Available: Immediately

---

---

---

---

---
