Komori Lithrone 1040 SP (2004)

أوفست ورقي Machine

الدولة الحالي: In stock

Last updated: 29-09-2026 | Viewed: 279 times - Enquiry's: 9

PD Ref: 141361

Dealer Ref.# 4010

العمر: 2004
Max.Size: 102 x 72 cm (40 x 28 inch)
الألوان: 10

No counter

Latest Enquiry for this machine was from Indian.

Extras: - Perfector

الوصف التقني:

Year: 2004
Condition: good
Counter. 91 Mil Impression but reality is approx. 200 Mil

Machine on stock

Technical specification:

Maximum sheet size: 720 × 1,030 mm
Minimum sheet size: 360 × 520 mm
Paper thickness: 0.07 – 0.30 mm
Maximum printing area: 705 × 1,020 mm
Maximum printing speed: 13,000 sheets per hour
Minimum printing speed: 3,500 sheets per hour
Printing plate:

Length × Width: 800 × 1,030 mm
Thickness: 0.30 mm
Blanket:

Length × Width: 900 × 1,040 mm
Inking unit:

Number of form rollers: 4
Form roller diameters: 87.5 – 77.5 – 85 – 90 mm
Number of rollers: 21 (lower unit) / 20 (upper unit)
Pile height:

Feeder: 1,430 mm
Delivery: 1,430 mm
Dimensions and weight:

Length × Width × Height: 11,022 × 4,037 × 3,383 mm
Weight (standard configuration): 64,220 kg (machine only)
Electrical specification:

Power consumption: 117.94 kW (machine only)
Frequency: 50 Hz

Specification:

Remote diagonal register adjustment (cocking).
Semi-automatic plate changing in the upper printing unit.
Semi-automatic plate changing in the lower printing unit.
AMR job presetting system: presetting of paper size and thickness, presetting of feeder table brushes / feed roller, presetting of feeder side air blowers, presetting of the side lay, and sheet drum brake position.
Automatic ink roller washing system.
Automatic blanket washing system.
Automatic impression cylinder washing system.
Lateral feeder pile adjustment (via shifting feeder).
Remote sucker height adjustment.
Water-cooled distributor rollers.
Oscillating ink form rollers: 2 × B and 2 × D for the upper and lower printing units separately.
Chrome-plated plate cylinder.
Chrome-plated impression cylinder (with special surface coating).
Chrome-plated blanket cylinder.
Combined Technotrans Beta.C 300L system for dampening solution cooling and ink temperature control (including CombiControl 4.3, Aquados C5, and integrated tank).
Grafix powder spray unit with Grafix powder spraying system.
