Mark Andy DigitalPro3 PLUS (2024)

---

Wiek: 2024
Max.Size: 33 x 0 cm (12 x 0 inch)

---

Opis techniczny:

Mark Andy Digital Pro3 PLUS
Hybrid Digital Printing Machine with Semi-Rotary Die-Cutting Unit
Installation: April 2024
Running meters: approx. 96,000 lfm from April 2024 to April 2026
Web width: 330 mm
Digital print width: max. 318 mm
Flexo print width: max. 330 mm
Digital resolution: 1200 x 1200 dpi
Digital printing speed: approx. 23.5 m/min
Digital printing: 4 colors
Flexo printing: 2 flexo units
Flexo drying: air-cooled LED UV
Materials: BOPP, PET, PP, paper
Digital Front End / RIP: PDF workflow
Power supply: 240 V, 50–60 Hz

Configuration and equipment:
Mark Andy Digital Pro3 PLUS hybrid digital press
2 flexo printing units
Semi-rotary die-cutting unit
Latest generation flexo printing stations
Semi-rotary die-cutting, expandable
Unwinder for laminate / KP available
Bypass for “flexo only” production or blank labels available
Rewinding system
Air-cooled LED UV drying
PDF digital workflow
Suitable for roll-to-roll label production
Accessories included:
2 x printing cylinders: 80Z and 96Z
1 x Spilker Airboy
Further accessories according to final confirmation
Technical highlights:
The machine offers a strong combination of digital printing, flexographic printing and semi-rotary die-cutting in one compact production line.
The uploaded technical specification confirms a maximum web width of 330 mm,
a digital print width of 318 mm, 1200 x 1200 dpi resolution and digital production speed of 23.5 m/min.
The layout drawing shows a complete production concept with unwind, semi-rotary die-cutting section, print station,
digital engine and rewind system, making the machine suitable for efficient short-run and medium-run label production.

---

Lokalizacja: Europe Western

---

---

Dostepny: Immediately

---

---

---

---

---
