Yawa 1050 E (2002)

Die Cutting PT Machine

Estado atual: In production

Ultima actualizacio: 29-09-2023 | Viewed: 468 times - Enquiry's: 10

PD Ref: 113003

Idade: 2002
Tamanho: 105 x 75 cm (41 x 29 inch)

Descricio:

YAWA 1050 E
Die cutting machine
2001 and installed in 2002
Sheet size Maxi 1050 x 750 mm
Mini 450 x 370 mm
Max die cutting area 1040 x 730 mm
Die cutting form size 1120 x 760 mm
Minimum form size 400 x 330 mm
Working stocks 0,1 mm à 3 mm
Maximum speed 7500 feuilles/heure
Minimum gripper edge 8 mm
Tork limitation on gripper bars tansmission
Digital reading of pressure settings
2 form holding chases
Quick lock system for small form
Dual axel centering system
2 -5 mm cutting plate
AUTOMATIC STRIPPING
Double action striping
Fast positionning of superior stripping chase with dual axel centering system
Dual axel centering system of stripping chase and board
Non stop delivery
Steel loading plate
Hight pile control by mechanical system
Platen angle position control
Touch screen operation control

Located in France. Free of any damage, in production.
Immediately available.
