Master Bag 400 4 Color Printing (New)

Sacos de papel Machine

Estado atual: In production

Ultima actualizacio: 22-05-2023 | Viewed: 786 times - Enquiry's: 0

PD Ref: 96521

Dealer Ref.# 239928

Idade: New
Tamanho: 25 x 22 cm (9 x 8 inch)

Descricio:

MASTER BAG 400 advanced series is applied to produce paper bags without handles, such as food paper bags, It is a piece of ideal equipment for producing mid-size and big-size paper bags fast. This machine is side gluing, roll folding, roll paper cutting, bottom folding, bottom gluing, bottom forming, bag out in one line. It is easy to operate, high efficient, stable, and effectively saves labor costs. The equipped photoelectric detector can correct cutting length, so as to ensure cutting precision. The equipped Yaskawa PLC system ensures that the machine can perform quickly and stably. Special bags collection platform and counting function, improve packing efficiency of paper bags packing. This machine can produce paper bags of varying greatly sizes at a high speed, thus is especially suitable for being applied in food, pharmacies, bakeries industries.

Paper bag length (L) 160-450mm

Paper bag width (W) 80-250mm

Side insert width(G) 20-120mm

Bag mouth height 15/20mm

Max. Paper bag speed 100-400pcs/min

Paper thickness 40-80g/m2

Paper roll width Max 800 mm

Paper roll diameter Dia1000mm

The inner diameter of the paper roll Dia 76mm

Print colors 4 colors

Max. Printing roller width 800mm

Max. Printing speed 50meter/mins

Printing plate thickness 2.38mm

Machine supply 380V, 50Hz, three-phase, four wires
• Power: 22 KW
• Weight: 6000 KGS
• Dimension: L 8500 x W 2200 x H 2500 mm
