Zechini Roby One.1 (2015)

Крышкоделательные машины Machine

Текущее состояние: In production

последнее обновление: 30-03-2026 | Viewed: 237 times - Enquiry's: 3

PD Ref: 140172

Произв: 2015
Макс.размер: 100 x 70 cm (39 x 27 inch)

Latest Enquiry for this machine was from Albania.

Описание:

Roby One.1
format 70x100cm
semi automatic case maker
equipped with additional hotmelt system for pattern gluing

Technical description:
The Zechini Roby 1.1 machine is designed for gluing and laminating paper, cardboard, fabrics, and plastics. It allows production of a wide range of products such as:
 one-piece binders
 multi-piece covers
 board games
 displays
 photo albums
 passports
 and many others
The special feeding system allows processing of sheets of any shape and size – both larger and smaller than the material being laminated.
The machine can operate with both cold glue and hot melt, ensuring high production flexibility.

Technical data:
 Max material size: 700 × 1000 mm
 Min material size: 150 × 150 mm
 Materials: from paper 80 g/m2 up to cardboard 4 mm thick
 Type of glue: cold glue or hot melt (4 heads)
 Max mechanical speed: 600 cycles/h
 Powersupply:380V/50Hz/3phase
 Power: 4 kW
 Compressed air consumption: 300 l/min at 6 bar
 Dimensions(L×W×H):160×250×140cm
 Weight: 960 kg
