Duplo System 5000 3x DSC-10 60i (2022)

Broşür yapımı Machine

Mevcut Durum: In production

Son güncelleme: 26-05-2026 | Viewed: 124 times - Enquiry's: 5

PD Ref: 141700

Dealer Ref.# 70272

Yaslilik: 2022
Max.Size: 50 x 35 cm (19 x 13 inch)

Latest Enquiry for this machine was from Russian.

Important: Very Good

Açiklama:

Duplo booklet maker System 5000

offer consists of:

- 3x collators DSC-10/60i
- bookletmaker DBM-500
- trimmer DKTS-200

Duplo System 5000
booklet maker

3xDSC-10/60i: collator
- number of bins: 30
- paper size:
width: min. 120mm, max. 350mm
length: min. 148mm, max. 500mm
- paper weight: 0-300g/sqm
- loading volume: 60mm
- feeding system: belt suction feed system
- conveyance system: roller belt conveyance system
- power supply: 120 to 240 V 50/60 Hz
- power consumption: 9.5A 120 V 60 Hz , 4.5A 220-240V, 50Hz

DBM-500: stitcher folder
- paper size: min. 120x170mm; max. 350x500mm
- process speed:
>5000 pcs/h, A5
>4600 pcs/h, A4
>4000 pcs/h, A3
- No. of stitches 0 to 2
- stitch thickness within 5mm
- wire diameter 25 to 27
- folding capacity: below 25 sheets
- dimensions: 2,230 W x 865 D x 1300 H
- ratings: 120 to 240 V 50/60Hz 6.5-3.8A
- weight: 412kg

We can also organize the following for you:

packaging, loading, transport by ship or plane including customs
