Bobst Fuego Mistral 80 A2 CS (2007)

Katlama-Yapıştırma Machine

Mevcut Durum: In production

Son güncelleme: 08-07-2026 | Viewed: 129 times - Enquiry's: 11

PD Ref: 142857

Dealer Ref.# QV59738

Yaslilik: 2007
Max.Size: 80 x 0 cm (31 x 0 inch)

Latest Enquiry for this machine was from India.

Important: Precision folder-gluer specializing in straight-line boxes with crash-lock A2 bottoms. Electronic gluing system with dual-head capability and integrated barcode quality control ensures 100- box integrity. Digital positioning system enables rapid format changes with minimum make-ready time.

Açiklama:

Type: Accufeed system with vibrator and tooth guide, Blank alignment: Automatic, left and right, Special features: High-precision blank positioning and orientation control, Configuration: Left and right pre-folding units, Transport system: Lower central transport with dual drive, Pre-crease capability: Glue flap pre-folding directly on belt with complete box control, Folding style: Straight-line fold Längsnaht , Box bottom module: A2 crash-lock bottom Faltboden , Corner device: Double corner Doppelrand , Upper glue unit: Electronic HHS system with 2 glue application heads, Lower glue unit: Disk-type glue station left side , Glue control: Electronically regulated for precision application, Quality assurance: HHS system with integrated barcode code reader Codeleser , Glue seam monitoring: Real-time glue line inspection, Faulty box ejection: Flipper ejector for 100% rejection of defective boxes, Video monitoring: Transfer station video surveillance system, Primary transport: Upper and lower central transport through folding section, Additional drives: Kickers for box separation and control, Nip belt system: Pneumatic, extra-long press belt for consistent nipping pressure, Main controller: Bobst C.U.B.E. Control Unit Bobst Electronics , Positioning system: CS Computer Set with digital indicators, Format memory: Multiple job presets with automatic position calculation, Operator interface: Mobile wireless remote control Funkfernbedienung , Digital displays: Real-time position and production data feedback, Type: Integrated delivery conveyor with belt transport system, Configuration: Modular conveyor with powered roller transport, Stacking platform: Collection and stacking area for finished boxes

Yer: Europe Western

Mevcut Durum: In production

Uygun: Immediately

Fiyat: Istek Üzerine
